53×26mm Aluminum Communication Module Enclosure

Boyuan 53×26mm aluminum enclosure is a wide, slim electronic device housing manufactured with an aluminum alloy extrusion structure, with an external cross-section size of 53mm (width) × 26mm (height), and the length can be customized arbitrarily according to actual equipment requirements.

53×26mm Aluminum Communication Module Enclosure is formed by aluminum profile extrusion, with a fixed main body cross-section size. It can be cut according to the actual length of the equipment, and final assembly is completed through end plates, CNC machining, and other supporting processes.

The aluminum extrusion electronic enclosure can be designed with corresponding mounting slots or support structures according to the internal structure, for installing PCBs and other electronic components. The interior of the housing is designed with standard circuit board card slots, and the PCB can be directly inserted and fixed without additional screws, greatly improving assembly efficiency.

Compared with plastic boxes, aluminum alloy enclosures have better structural strength and a metal texture, and can achieve custom structures such as interfaces, mounting holes, threaded holes, and slots through CNC machining.

Core Advantages

01 | 53×26mm Wide and Slim Design

The 53mm wide × 26mm high cross-section size provides an ideal packaging solution for electronic equipment.

The 53mm width is wider than the common 52mm specification, accommodating wider PCB layouts and more side-by-side interface design, supporting multi-channel input/output interface layouts; the 26mm height maintains a slim device appearance while providing greater component mounting space than slim specifications, accommodating small transformers, electrolytic capacitors (typically 20-25mm in height), relays, and medium-height components, supporting the integration needs of relatively complex circuit systems.

02 | Aluminum Extrusion Structure

The enclosure body is formed by aluminum alloy profile extrusion. The cross-section size of the aluminum extrusion enclosure is fixed, while the length can be cut according to actual product requirements. Therefore, the same specification enclosure can adapt to PCBs and electronic modules of different lengths. This structure is especially suitable for electronic products requiring series development.

03 | Suitable for PCB Mounting

The aluminum extrusion electronic enclosure can be designed with corresponding mounting slots or support structures according to the internal structure, for installing PCBs and other electronic components. The interior is standard-equipped with circuit board card slots, and the PCB can be directly inserted and fixed without additional screws.

04 | CNC Custom Machining Support

The standard profile is only the starting point. Boyuan Hardware can perform CNC machining on the 53×26mm aluminum enclosure according to customer drawings, including:

• Interface openings (USB, RJ45, aviation plugs, BNC interfaces, power interfaces, SMA antenna interfaces, etc.)
• Screw holes and positioning holes
• Threaded holes and counterbore holes
• Heat dissipation slots and ventilation holes
• Screen window openings
• Button holes and switch holes
• Mounting holes and wall-mounting holes
• Grooves and steps
• Chamfering
• Other custom structures

05 | Length Customizable to Product

53×26mm is the cross-section specification of the enclosure, and the product length can be cut according to the actual equipment dimensions. The specific machinable length is confirmed according to material, surface treatment, and product requirements.

06 | Efficient Heat Dissipation Performance

Aluminum alloy has excellent thermal conductivity. Combined with the 53mm wide-body design, it can effectively help internal components dissipate heat and extend equipment service life.

07 | Metal Enclosure Combines Structure and Appearance

Aluminum alloy is lightweight and has good structural performance, while retaining a natural metal texture. Through surface treatments such as brushing, sandblasting, and anodizing, different appearance effects can be obtained, giving electronic equipment a more professional product appearance.

Technical Specifications

Note: Specific material grades, wall thickness, length ranges, dimensional tolerances, and surface treatment colors shall be subject to actual product drawings and order requirements.

What Products Is the 53×26mm Aluminum Enclosure Suitable For?

53×26mm belongs to the wide-body slim aluminum enclosure category — the 53mm width is wider than the common 52mm specification, providing ample PCB layout space and more side-by-side interface layout; the 26mm height maintains a slim appearance while providing greater internal space than slim specifications. This specification is widely used in instruments, meters, electronics, communications, automation, sensors, smart cards, industrial control, precision machinery, and other industries.

1. Communication Modules and Wireless Equipment

The wide-body design of 53×26mm is very suitable for various communication products:

• Communication modules
• Wireless platforms
• GPS/GPRS enclosures
• Signal conversion modules
• Signal booster enclosures
• Wireless platform terminals
• Data transmission modules
• Video servers
• Routers, wireless receivers
• RF module enclosures

Why is 53×26mm suitable for communication modules? Communication modules usually need a wider PCB layout to accommodate RF circuits, antenna interfaces (SMA), power interfaces, data interfaces, and other functional modules. The 53mm width can accommodate more antenna interfaces and communication interfaces placed side by side, and the 26mm height can accommodate small transformers and medium-height components.

2. Power Modules

• Switching power supply modules
• Power adapters
• Vehicle power supply enclosures
• Inverter enclosures
• Rectifier aluminum housings
• DC-DC converter modules
• Charger modules
• Communication power supplies

Why is 53×26mm suitable for power modules? Power modules usually need to accommodate components such as electrolytic capacitors (typically 20-25mm in height), small transformers, and heat sinks. The 26mm height provides ample mounting space, and the 53mm width can accommodate wide PCB layouts, supporting multi-channel input/output interfaces.

3. Measuring Instruments and Testing Equipment

• Instrument and meter enclosures
• Data acquisition instruments
• Signal generator enclosures
• Power analyzers
• Testing equipment
• Precision measuring instruments
• Oscilloscope modules

4. Industrial Control and Automation Modules

• Industrial controllers
• Programmable logic controller (PLC) modules
• Motion control modules
• Motor drive modules
• I/O expansion modules
• Automation control equipment
• Industrial control chassis supporting modules

5. Shielding Boxes and Anti-Interference Applications

The 53×26mm aluminum enclosure can serve as a good electromagnetic shielding solution:

• Electronic shielding boxes
• Anti-interference device enclosures
• High-frequency module shielding
• Precision circuit protection boxes

The aluminum alloy material itself has good electromagnetic shielding performance, effectively preventing electromagnetic interference.

6. Sensors and Smart Devices

• Sensor modules
• Data acquisition terminals
• Smart card devices
• IoT terminals

7. Medical and Testing Equipment

• Medical equipment enclosures
• Testing modules
• Monitoring equipment modules
• Portable medical instruments

8. Public Address and Audio Equipment

• Public address system equipment
• Amplifier circuits
• Audio equipment

What Can Be Customized?

Surface Treatment

Anodizing

Anodizing is one of the commonly used surface treatment methods for aluminum enclosures. It can change the appearance and surface properties of the aluminum surface and achieve different color effects.

Sandblasting

Sandblasting can form a uniform matte texture on the aluminum surface, suitable for industrial electronic equipment and instrument enclosures.

Brushing

Brushing can form regular metal textures, allowing the product to maintain an obvious aluminum alloy metal texture.

Laser Engraving

The following can be machined on the surface of the 53×26mm aluminum enclosure:

• Logo
• Product model
• Interface identification
• Product number
• Text and patterns

Silkscreen Printing

Suitable for machining multi-color logos, text, and function identification.

Professional Aluminum Enclosure Custom Machining

We not only produce standard aluminum enclosures, but can also customize according to customer product structures.

Customers only need to provide:

2D drawings / 3D models / physical samples / product dimensions

We can then perform machining evaluation according to actual product requirements.

CNC Machining Meets Non-Standard Requirements

For products that cannot be directly satisfied by the 53×26mm standard profile, customization can be achieved through subsequent CNC machining.

For example:

Interface openings + screen windows + mounting holes + threaded holes + heat dissipation slots + grooves + steps + logo

All can be machined according to customer drawings.

Product Selection Guide

If Your PCB Width Is Close to 53mm

53×26mm is an ideal choice — the 53mm width provides more ample PCB routing space and more side-by-side interface layout than the common 52mm specification.

If Your Device Contains Medium-Height Components

The 26mm height can accommodate small transformers, electrolytic capacitors (20-25mm), relays, and medium-height components, suitable for electronic equipment requiring a certain internal vertical space.

If Your Device Needs a Slim Appearance

The 26mm height maintains a slim appearance while providing greater internal space than the 21-22mm specifications, balancing aesthetics and functional completeness.

If You Need Compatibility with Multiple Interfaces

The 53mm width supports side-by-side layout of multiple interfaces such as RJ45, aviation plugs, BNC, USB, and SMA antenna interfaces, suitable for communication and measurement equipment requiring rich interfaces.

If Your Device Needs Good Heat Dissipation

The aluminum alloy enclosure has excellent thermal conductivity. Combined with the 53mm wide-body design, it can effectively help internal components dissipate heat.

If PCB Lengths Differ

The profile can be cut according to product length, and the same cross-section specification can adapt to products of different lengths.

Workshop Show

FAQ

1. What products is the 53×26mm aluminum enclosure suitable for?

53×26mm belongs to the wide-body slim aluminum enclosure category, suitable for communication modules, wireless platforms, GPS/GPRS enclosures, signal boosters, power modules, instruments and meters, data acquisition equipment, video servers, industrial controllers, shielding boxes, etc. The 53mm width provides ample PCB layout space, and the 26mm height accommodates medium-height components while maintaining a slim appearance.

2. Is 53×26mm the length of the enclosure?

No. 53×26mm refers to the cross-section size of the enclosure (width × height). The product length can be cut according to actual equipment and PCB length.

3. Can the length of the 53×26mm aluminum enclosure be customized?

Yes. The length of the aluminum extrusion enclosure can be cut according to product requirements. The specific length needs to be confirmed in combination with material, surface treatment, and product structure.

4. Can the 26mm height accommodate electrolytic capacitors?

Yes. Common electrolytic capacitors are usually 20-25mm in height, and the 26mm internal height can fully accommodate them. Specific confirmation is needed according to your component dimensions.

5. What is the difference between 53mm width and 52mm?

53mm is 1mm wider than the common 52mm specification. Although the difference is small, it provides more ample space for PCB routing and makes it easier to accommodate more interfaces side by side, especially suitable for communication equipment requiring multiple interfaces.

6. Can heat dissipation holes be made on the aluminum enclosure?

Yes. Boyuan Hardware can machine heat dissipation slots, ventilation holes, and other heat dissipation structures according to customer drawings to help equipment dissipate heat.

7. Can SMA antenna interfaces be machined?

CNC machining can be performed on the corresponding interface positions according to customer drawings. The 53mm width can accommodate side-by-side layout of multiple interfaces. Whether it is specifically suitable for machining needs to be confirmed according to interface dimensions and enclosure structure.

8. Can a PCB be installed?

Yes. The 53×26mm aluminum enclosure is standard-equipped with internal circuit board card slots, and the PCB can be directly inserted and fixed without additional screws. Corresponding mounting structures can also be designed according to PCB dimensions and mounting method.

9. Can end plates be customized?

Yes. The dimensions, hole positions, and structure of the end plates can be machined according to product requirements.

10. Can a logo be made?

Yes. Logo machining methods such as laser engraving or silkscreen printing can be selected according to product requirements.

11. Can different colors be selected?

Yes. The aluminum enclosure can achieve different appearance effects through processes such as anodizing, and the color can be arbitrarily customized according to customer requirements.

12. What if 53×26mm is not suitable for my PCB?

You can send us the PCB dimensions, product structure, or 3D model. Boyuan Hardware can help confirm whether the 53×26mm specification is suitable according to actual dimensions, and can also choose other aluminum profile specifications or perform custom machining.

13. Can samples be made first?

Sample machining can be performed according to project requirements. It is recommended to confirm the sample dimensions, hole positions, assembly, and surface effect before mass production.

Why Choose Boyuan Hardware?

For electronic equipment manufacturers, what matters more is whether the supplier can complete supporting machining such as length, end plates, interface openings, screen windows, mounting holes, heat dissipation structures, PCB structures, surface treatment, and logos according to the actual product.

Boyuan Hardware has focused on the aluminum enclosure and aluminum chassis industry for over 20 years, with approximately 10,000 square meters of production factory space, providing custom aluminum enclosure machining.

From the standard 53×26mm aluminum profile to the CNC-machined finished electronic enclosure, we can machine according to customer product requirements.

If you are looking for a 53×26mm Aluminum Communication Module Enclosure, you are welcome to send your PCB dimensions, product drawings, or 3D models.

We can confirm the specification, machining method, and customization plan according to your product structure.
