52mm Desktop Aluminum Extrusion Chassis for Electronic Equipment

52mm Desktop Aluminum Extrusion Chassis for Electronic Equipment adopts an aluminum profile structure. The chassis height is fixed at 52mm, and the length and width can be customized according to PCB dimensions, internal component layout, and overall equipment dimensions.

Compared with low-profile chassis such as 30mm, 34.9mm, and 35mm, the 52mm height provides more ample internal mounting space, making it more suitable for desktop electronic equipment that needs to accommodate more electronic components, interfaces, power modules, or internal structural parts.

Product Structure

Core Advantages

1. 52mm Fixed Height, Providing More Ample Internal Space

Compared with low-profile chassis, the 52mm height provides more vertical internal space.

For equipment that needs to simultaneously install:

· PCBs

· Electronic components

· Interface assemblies

· Power modules

· Internal brackets

· Connecting cables

it can reduce internal layout problems caused by height restrictions.

Therefore, this height is more suitable for desktop electronic equipment that requires a certain amount of internal space.

2. Desktop Structure, Suitable for Standalone Electronic Devices

The 52mm height is suitable for making electronic devices with a certain amount of internal space that need to be placed and operated independently.

Compared with the 42.5mm chassis that needs to be embedded inside equipment, this product can be more oriented toward:

Desktop devices, electronic instruments, test modules, control equipment, and standalone electronic modules.

3. Length and Width Customizable to Equipment Dimensions

The 52mm height is fixed, but the length and width can be adjusted according to the actual product.

The final dimensions can be determined in combination with:

· PCB dimensions

· Component layout

· Number of interfaces

· Power modules

· Internal mounting structure

· Desktop footprint

This avoids the mismatch between standard chassis dimensions and actual electronic products.

4. PCB Card Slots for Convenient Circuit Board Mounting

The chassis interior is provided with PCB card slots, which can be used for circuit board positioning and mounting.

For desktop electronic devices, the PCB can be positioned along the chassis internal structure, while leaving mounting space for other internal components.

5. Internal Mounting Grooves Support Multi-Component Layout

The 52mm height provides greater vertical space, and combined with internal mounting grooves, different electronic modules and structural parts can be installed according to the product structure.

For equipment with more internal components, the positions of the PCB, power supply, interfaces, and other components can be planned more flexibly.

6. Aluminum Profile Structure Balances Support and Heat Dissipation

The aluminum profile chassis body can provide stable structural support, while using the thermal conductivity of aluminum to help the device dissipate heat.

For specific heat dissipation requirements, it needs to be determined in combination with the power of electronic components, internal layout, and actual thermal design.

7. Front and Rear Panels Can Be CNC-Machined According to Function

The front and rear panels can be machined according to actual product drawings, including:

· Power interface holes

· USB interface holes

· Communication interface holes

· Indicator light holes

· Button holes

· Mounting holes

· Other special-shaped holes

Suitable for desktop electronic equipment requiring multiple external interfaces.

Technical Specifications

Applicable Fields

This model is recommended to highlight desktop, instrument, test, and standalone electronic equipment, clearly distinguishing it from the preceding 42.5mm embedded applications.

1. Desktop Electronic Equipment

Suitable for electronic devices that need to be placed independently on a desktop.

The 52mm height can provide relatively ample internal space, while the custom length and width can be adjusted according to device functions and PCB dimensions.

2. Small Test and Measurement Equipment

Suitable for some small test equipment that needs to install PCBs, interfaces, power supplies, and internal electronic modules.

The front and rear panels can be machined according to test interfaces, communication interfaces, and power interfaces.

3. Data Processing and Acquisition Equipment

For equipment that needs to integrate PCBs, data interfaces, power modules, and communication modules, the 52mm height can provide more flexible internal layout space.

4. Control and Operation Modules

Suitable for some control modules, electronic control devices, and operating equipment that require an independent chassis structure.

The panels can be CNC-machined according to the positions of buttons, indicator lights, and interfaces.

5. Communication and Interface Equipment

Suitable for desktop electronic equipment that needs to install multiple communication interfaces, connectors, or data interfaces.

The chassis length and width can be adjusted according to the number of interfaces and PCB layout.

Customizable Items

Workshop Show

3-Axis CNC Machining Capability

Boyuan Hardware currently mainly uses 3-axis CNC machining and can complete subsequent machining of the 52mm aluminum profile chassis and panels according to product drawings.

Machinable:

· CNC openings

· Drilling

· Tapping

· Mounting holes

· Interface holes

· Panel special-shaped holes

· Counterbore/countersink holes

· Logo and marking

· Other structural machining

The specific machining content is determined according to product drawings and structural requirements.

Quality Inspection

According to product requirements, the following can be carried out:

· Profile appearance inspection

· Length dimension inspection

· CNC machining dimension inspection

· Hole position inspection

· Thread inspection

· Panel dimension and appearance inspection

· Surface treatment appearance inspection

· Assembly inspection

· Finished product appearance inspection

For products with explicit dimensional tolerance requirements, inspection can be carried out according to customer drawings and technical requirements.

FAQ

Q1. Is the height of this chassis fixed?

Yes. The height of this model is fixed at 52mm, while the length and width can be customized.

Q2. Can the chassis be used as a desktop electronic equipment chassis?

Yes. The 52mm height provides additional internal space for PCBs, electronic components, interfaces, and internal mounting structures, making it suitable for compact desktop electronic equipment.

Q3. Can I customize the length and width?

Yes. The length and width can be customized according to the PCB dimensions, internal components, and overall equipment requirements.

Q4. Does the 52mm Desktop Aluminum Extrusion Chassis for Electronic Equipment have a PCB slot?

Yes. The aluminum extrusion structure includes an internal PCB slot for PCB positioning and installation.

Q5. Can the front and rear panels be customized?

Yes. The panels can be CNC machined according to interface, mounting, indicator, and button requirements.

Q6. Can mounting holes and threaded holes be added?

Yes. Mounting holes, drilled holes, and threaded holes can be machined according to the product drawing.

Q7. Does the aluminum chassis provide heat dissipation?

The aluminum extrusion structure provides a heat dissipation path. For specific thermal requirements, the design should be determined according to component power and internal layout.

Q8. Can the color be customized?

Yes. Surface finish and color can be customized according to product requirements.
